Minimum DC Link Capacitance for a Family of Three-Phase Three-Level Grid-Connected Converters
This article presented the outcomes of a preceding study, which focused on the generalization of split DC link voltages behavior in three-phase-level converters operating with arbitrary power factor. This previous study served as the foundation for the development of equations governing the minimum capacitance necessary to ensure the proper operation of the inverter. Due to the prevalence of a third harmonic component in the DC link capacitor voltage, a lack of synchronization exists between the minimum value of the capacitor voltage and the maximum value of the grid voltage. This phenomenon enables the capacitor voltage to be slightly reduced below the peak of the mains voltage by appropriately selecting the capacitor or a set DC voltage.
